主要技術參數:
|
參數(Item): 型號(Model): |
CK6140*1000 |
|
|
加工能力 CAPACITIES |
床身上最大回轉直徑Max.swing over bedmm4 |
400 |
|
刀架上最大回轉直徑Max.swing over arriagemm |
200 |
|
|
最大車削長度Max truning length |
1000 | |
|
床身寬度Bed width |
360 |
|
|
行程 |
X軸行程Xaxis travelmm |
280 |
|
Z軸行程Yaxis travelmm |
1000 |
|
|
主軸 |
主軸轉速范圍Spindle speed rpm |
70~1600無極變速 |
|
主軸端部尺寸Spinele nosemm |
C8 |
|
|
主軸內控錐度Spindle taper |
MT6 |
|
|
主軸通孔直徑Spindle hole |
82 |
|
|
刀架 |
刀具數量Number of stations |
4 |
|
刀柄尺寸Tool shank sizemm |
25×25 |
|
|
換刀時間Indexing timesec |
2.0 |
|
|
進給 |
X軸快速進給Rapid traverse of X axismm/min |
5000 |
|
Z軸快速進給Rapid traverse of Z axismm/min |
5000 |
|
|
每轉切削進給量Cutting feed X and Z axismm/r |
0.005-100 |
|
|
尾座 |
尾座套筒錐度Taper of tailstock sleeve |
MT5 |
|
尾座套筒直徑Dia.of tailstock sleeve |
75 |
|
|
尾座套筒行程Travel of tailstock sleeve |
150 |
|
|
電機 |
主電機功率Main motor power kw |
5.5/7.5 |
|
X軸、Z軸電機X and Z axis motor Nm |
4/6 |
|
|
長×寬×高L×W×H mm |
2600×1500×1700 |
|
|
凈重Net weight kg |
2700 |
|
|
數控系統Type of CNC Controller |
||
如因技術改進，參數發生變化，恕不另行通知
